OPERATION CONTROL CENTER FOR PC1 GROUP
Investor: PC1 Group.
Our scope:
– Supply, install, and configure computer system and network system.
– Connect data from wind power plants to the operation control center.
– Design, configure, and connect user interface, signals, database, firewall, and VPN.
– Intergrate business intelligence (BI) function to the SCADA system.
500KV TRUNG NAM SUBSTATION
Investor: Trung Nam Group.
Our scope:
– Computer-based Control System, SCADA System, and FR/PQ/PMU System configuration, applying the IEC61850 protocol.
– Configuration for Gateway and coordinating for Point-to-Point and End-to-End commisioning by IEC 60870-5-104 protocol.
HMI/SCADA software: SICAM PAS by Siemens
SCADA SYSTEM IN 220KV PTC1 SUBSTATIONS
Investor: Power Transmission Company No.1, EVN.
Our scope:
– Upgrading SCADA system that includes IEC61850, IEC60870-5-103, IEC60870-5-101, Modbus RTU protocols, and IEDs from Siemen, ABB, Toshiba, Sel, Nari, Micom, etc.
– HMI design and connection of signal to Northern Load Dispatch Centre.
HMI/SCADA software: ZENON by COPA-DATA
Locations:
220kV substation – Chem, Ha Dong, Thai Nguyen, Hoanh Bo, Thai Binh, Ninh Binh, Nghi Son, and Hung Dong.
OPERATION CONTROL CENTER IN NORTHERN DISTRIBUTION GRID
Investor: Northern Power Corporation, EVN.
Our scope:
– Configuration of IED/BCUs for bay control, collect and handle the signals, applying the IEC61850 protocol.
– Collecting measurement signal from meters which used Modbus RTU protocol.
– Connection of information and signals to the OCC in 3 provinces with IEC60870-5-104 protocol.
HMI/SCADA software: zENON by COPA-DATA.
Locations:
110kV substation – Thuan Chau, Phu Yen, Song Ma, Lac Son, Mai Chau, Hoa Binh, Vinh Tuong, Lap Thach, Moc Chau, Son La, Muong La, Luong Son, Trung Son, Thanh Nong, Vinh Yen, Phuc Yen, and Thien Ke.
PHUOC THAI SOLAR POWER PLANT & 220KV SUBSTATION
Investor: Projects Management Board No.3, EVN.
Our scope:
– Supply control, protection, auxiliary system, and FR/PMU/PQ system with protocols such as IEC 61850, IEC 60870-5-104, Modbus, etc.
– Configurate CSCS/SCADA system software.
– Coordinate for Point-to-Point and End-to-End testing of FR/PQ/PMU and SCADA system.
HMI/SCADA software: SICAM PAS by Siemens.
TRUC SON SOLAR POWER 110KV SUBSTATION
Investor: TTC Group.
Our scope:
– Configurate SCADA system, computer-based control system, and Siemens FR/PQ/PMU system with protocols such as IEC 61850, Modbus, etc.
– Coordinate for Point-to-Point and End-to-End commissioning of FR/PQ/PMU and SCADA system by IEC 60870-5-104
HMI/SCADA software: SICAM PAS by Siemens.
110KV TAY NGUYEN WINDFARM SUBSTATION
Investor: HBRE Wind Power Solution., JSC.
Our scope in 1st Stage:
– Configuration of IED/BCUs for bay control, collecting and processing the signals, applying the IEC61850 protocol.
– Measurement signal collection from meters by Modbus RTU protocol.
– Connect all informations, signals to the OCCs, NLDC (A0), CRLDC (A3) by IEC60870-5-104 protocol.
– Coordinate with NLDC (A0), CRLDC (A3), and Power Plant for Point-to-Point and End-to-End commissioning.
Our scope in 2nd Stage:
– Configuration for connection between 110kV CSCS system with GE Wind Power system (WindCONTROL, WindSCADA).
– COD (Commercial Operation Day) testing with NLDC (A0), CRLDC (A3) and Power Plant.
HMI/SCADA software: ZENON by COPA-DATA
220kV SON LA SUBSTATION SCADA UPGRADE
Investor: Power Transmission Company No.1
Our scope:
– Upgrade hardware and firmware of Areva MiCOM C264 and configure IEC 61850, IEC 60870-5-103, Modbus RTU for BCU communication.
– Upgrade network system of SCADA system, apply PRP protocol and RSTP protocol for IEDs.
– Upgrade measurement system and transformer control system in electrical cabinet.
– Upgrade PACiS system with PACiS SUI, EcoSUI HMI, SBus Server, Eco GTW and new IEC61850 engineering tools.
HMI/SCADA software: PACiS SAS system by Schneider Electric.
| No | Projects | Time | End-user |
|---|---|---|---|
| 1 | Supply of materials, equipment and installation of RTU/SCADA system for Vinpearl Bai Dai - Khanh Hoa project | 2016 | VinPearl |
| 2 | Supply of materials, equipments and installation of RTU/SCADA system for Fire monitoring system in 110kV substations | 2016 | EVNNPC |
| 3 | Supply of materials, equipment and installation and CSCS/SCADA configuration services for Long Bien 110kV substation | 2016 | EVNHANOI |
| 4 | Supply services of "Protection configuration, intergrate PCS931/NR relays of 110 feeders in 220kV PhuLy substation" - PCS9700 CSCS system (NR/China) | 2016 | EVNPTC1 |
| 5 | Supply configuration services for CSCS/SCADA system of projects: "Raising the capacity of T2-E1.3 transformer 220kV Mai Dong" (LSA System - Siemens) | 2016 | EVNPTC1 |
| 6 | Supply configuration services for "OCC Control Centre of 110kV substations of Son La Province" Stage 1 | 2016 | EVNNPC |
| 7 | Supply configuration services for "OCC Control Centre of 110kV substations of Hoa Binh Province" Stage 1 | 2016 | EVNNPC |
| 8 | Supply configuration services for "OCC Control Centre of 110KV substations of Vinh Phuc Province" Stage 1 | 2016 | EVNNPC |
| 9 | Supply CSCS software and services: "Repairing and replacing RTU equipment of 220kV Thanh Hoa substation" | 2016 | EVNPTC1 |
| 10 | Supply of materials, equipment and installation RTU system of Vinpearl Le Thanh Tong - Khanh Hoa | 2017 | VinPearl |
| 11 | Supply of materials, equipment and installation RTU system of Vincom S1 - Khanh Hoa | 2017 | VinCom |
| 12 | Supply of materials, equipment and installation RTU fire monitoring system of 110kV Minh Hai substation | 2017 | EVNNPC |
| 13 | Supply CSCS/SCADA software 110kV Minh Hai substation | 2017 | EVNNPC |
| 14 | Supply configuration services CSCS/SCADA SICAM PAS (Siemens) system in 110kV Linh Dam substation of project "Installation T3 transformer of 110kV Linh Dam substation" | 2017 | HANOI PC |
| 15 | Supply 05 protection relays P543/GE and O/E converter for 05 110kV line feeders in 500kV West Hanoi | 2017 | EVNPTC1 |
| 16 | Supply configuration services for "OCC Control Centre of 110kV substations of Vinh Phuc Province" Stage 2 | 2017 | EVNNPC |
| 17 | Supply configuration services for "OCC Control Centre of 110kV substations of Son La Province" stage 2 | 2017 | EVNNPC |
| 18 | Supply configuration services for "OCC Control Centre of 110kV substations of Hoa Binh Province" stage 2 | 2017 | EVNNPC |
| 19 | Supply services "Protection configuration, intergrate protection relays F79/50BF for 220kV feeders on 220kV Hai Duong station (Celeste System - Remsdaq/UK) | 2017 | EVNPTC1 |
| 20 | Supply services "Configuration of CSCS/SCADA system of 220kV Thanh Hoa substation" under "Package 5: Supply and intallation SCADA system at 220kV Thanh Hoa 220kV Substation, the project: Installing capacitors on the transmission grid in the North of VN" | 2017 | EVNPTC1 |
| 21 | Supply services and construction organizations to complete the items under: "Package No. 2: Supplying and transporting secondary equipment and materials and executing SCADA works and projects: Installing 01 110kV line feeder in 220kV Vinh S/S" | 2018 | EVNPTC1 |
| 22 | Supply materials and services for CSCS/SCADA system: "110kV Phong Dien substation Wind power" - Eahleo - Daklak | 2018 | HBRE |
| 23 | Supply CSCS/ SCADA configuration services project "Increasing capacity of 220kV Nghi Son substation from (125+250) MVA to (2x250) MVA" | 2018 | EVNPTC1 |
| 24 | Supply of materials, equipment and installation of RTU system (auxiliary monitoring system) of Cat Hai project - Hai Phong | 2018 | ACIT |
| 25 | Supply Services CSCS/ SCADA completed the items under: "Delete T grid 03 stations at Power Transmission Company No1: Chem, Ha Dong, Vinh" | 2018 | EVNPTC1 |
| 26 | Supply services: "Configuring 16 sets of REF611 and REF615 relays of ABB" at HANWA - Hoa Lac aircraft engine manufacturing plant | 2018 | HANWA |
| 27 | Supply SMS alarm & control equipments for distribution grid | 2018 | EMB |
| 28 | Supply configuration services CSCS/SCADA system of 220kV Hai Duong 1 substation under the project "Raising the capacity of Hai Duong 220kV substation 1 from 125MVA to 250MVA" | 2018 | EVNPTC1 |
| 29 | Supply Services: "Protection configuration, configuration CSCS/SCADA system at 220kV Thai Binh, relay of feeder 173 according to the project: Special load shedding 173 line feeder, 220kV Thai Binh substation"; "Protection configuration, configuration CSCS/SCADA system at 220kV Vinh Yen relay of feeder 175 according to the project: Special load shedding 175 line feeder, 220kV Vinh Yen substation"; "Protection configuration, configuration CSCS/SCADA system at 220kV Hai Duong 1 relay of feeder 175 according to the project: Special load shedding 175 line feeder, 220kV Hai Duong 1 substation" | 2018 | EVNPTC1 |
| 30 | Supply services of Configuration SCADA system. Project "Raising the capacity of 220kV Nghi Son substation from (125+250) MVA to 2x250MVA" | 2018 | EVNPTC1 |
| 31 | Supply services of Configuration CSCS/SCADA system. Project "Raising the capacity of 220kV Nghi Son substation from (125+250) MVA to 2x250MVA" | 2018 | EVNPTC1 |
| 32 | Supply services of configuration CSCS/SCADA system SICAM PAS (Siemens) in 500kV Dong Anh. Project "500kV transformer extension" | 2018 | EVNPTC1 |
| 33 | Supply secondary control & protection cubiles, CSCS/SCADA software and configuration services. Project "110kV substation Ninh Phuoc 6.2 and 110kV connection line" and "Ninh Phuoc 6.1 & 6.2 Solar Power Plant" | 2019 | NISTA |
| 34 | Supply services of Configuration CSCS/SCADA SICAM PAS /SIEMENS system: 110kV Truc Son substation - Truc Son Solar Power Plant | 2019 | TTC |
| 35 | Supply services of Configuration CSCS/SCADA system. Project "Extension 02 110kV Line feeders in 220kV Nghi Son Substation" | 2019 | EVNPTC1 |
| 36 | Supply services of Configuration CSCS/SCADA system. Project "Replacement relay in 100 feeder and 431 feeder of 220kV Quang Ninh S/S" | 2019 | EVNPTC1 |
| 37 | Supply material, CSCS/SCADA software and configuration services for Cam Hoa solar Power Plant. Project "50MW Cam Hoa Solar Power Plant" - Cam Xuyen - Ha Tinh Province | 2019 | HOANH SON Group |
| 38 | Supply lan-switchs and configuration services for 220kV Vinh Yen, 220kV Lao Cai. Project "Replacement lanswitchs in 220kV Vinh Yen, 220kV Lao Cai" | 2019 | EVNPTC1 |
| 39 | Supply CSCS/SCADA software, FR/PQ.PMU system and configuration services. Project "110kV BauZon Substation at BauZon solar power plant" | 2019 | TT. Sunglim |
| 40 | Supply services "Protection configuration, intergrate protection relays F87L -feeder 178 of 220kV Chem substation" | 2019 | EVNPTC1 |
| 41 | Supply services "Installation, configuration, BCUs, CSCS System for changing setting group of 220kV feeders at 220kV Phu Ly substation" | 2019 | EVNPTC1 |
| 42 | Supply services "Configuration of SCADA System , P2P and E2E testing 04 110kV line feeders at 220kV Trang Bach substation" | 2019 | EVNPTC1 |
| 43 | Supply services "Configuration of SCADA System , P2P, E2E testing 02- 110kV line feeders at 220kV Yen Bai substation" | 2019 | EVNPTC1 |
| 44 | Supply services "Configuration of CSCS/SCADA system" in Project "Extension 01 110kV Reactor at 220kV Son La Substation" | 2019 | EVNPTC1 |
| 45 | Supply services "Configuration of CSCS/SCADA system" in Project "Extension 01 110kV Line feeder at 220kV Son La Substation" | 2019 | EVNPTC1 |
| 46 | Renovation of computing system and measuring signal at 110kV - Ciputra Substation (Pacis/Alstom System) | 2019 | CITRA |
| 47 | Supply secondary control & protection cubicles, CSCS/SCADA software, FR/PQ/PMU system and configuration services. Project "110kV Dai Phong substation and 110kV connection line" in Project "Dai Phong Windfarm Plant" | 2020 | The BlueCircle |
| 48 | Supply secondary control & protection cubicles, CSCS/SCADA software, FR/PQ/PMU sustem and configuration services. Project "220kV PhuocThai 1 Substation" in project "PhuocThai 1 Solarfarm Plant" | 2020 | EVNPMB3 |
| 49 | Supply secondary control & protection cubicles, CSCS/SCADA software and configuration services. Project "PhuocThai 1 SolarFarm Plant" | 2020 | EVNPMB3 |
| 50 | Supply computer control configuration services and SCADA systems, FR/PMU/PQ systems in Trung Nam 500kV substation, Thuan Nam | 2020 | Trung Nam Group |
| 51 | Supply secondary control & protection cubicles, CSCS/SCADA software, FR/PMU/PQ systems and configuration services. Project "Phu My 220kV Substation" | 2020 | EVNPTC1 |
| 52 | Supply secondary control & protection cubicles, CSCS/SCADA software, FR/PMU/PQ systems and configuration services. Project "Tra Vinh Wind farm 110kV Substation" | 2020 | NTNN |
| 53 | Supply secondary control & protection cubicles, CSCS/SCADA software, FR/PMU/PQ systems and configuration services. Project "Phan Lam 2 Solor farm 110kV Substation" | 2020 | NLPL |
| 54 | Supply secondary control & protection cubicles, SCADA and computer configuration services. Project "Upgrading computer control system in Son La 220kV Substation substation" | 2020 | EVNPTC1 |
| 55 | Supply secondary control & protection cubicles, power plant supervisory, and PPC. Project "Dohwa-Le Thuy Solarfarm Plant" | 2020 | Dohwa |
| 56 | Supply secondary control & protection cubicles, power plant supervisory, and PPC. Project "My Hiep Solarfarm Plant" | 2020 | VVN |
| 57 | Configuration and commissioning for miniSCADA system of Grand World Phu Quoc | 2021 | |
| 58 | Supply and configuration for PPC system of Phong Dien 2 solar power plant | 2021 | |
| 59 | Supply and configuration for computer-based control, CSCS/SCADA, FR/PMU/PQ system of 110kV Quoc Vinh substation - Quoc Vinh Soc Trang wind power plant project | 2021 | |
| 60 | Supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Lac Hoa 1 substation - Lac Hoa 1 wind power project | 2021 | |
| 61 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ, FL system of 220kV BIM substation - BIM wind power plant project | 2021 | BIM WIND |
| 62 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Huong Tan substation - Lien Lap wind power plant project | 2021 | PL WP |
| 63 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ, FL system of 220kV Huong Tan substation - Lien Lap wind power plant project | 2021 | PL WP |
| 64 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Ia Bang substation - Ia Bang 1 wind power plant project | 2021 | GEC |
| 65 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ, FL, and operation control center system of 220kV Iapet substation, 500kV Pleiku 3 substation - Ia Pet Dak Doa 1&2 wind power plant project | 2021 | IA PET DAK DOA WPP |
| 66 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ, FL system of 220kV Hung Hai substation - Hung Hai Gia Lai wind power plant project | 2021 | |
| 67 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Hanbaram 1 substation - Hanbaram 1 wind power plant project | 2021 | HANBARAM WIND POWER JSC |
| 68 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Hanbaram 2 substation - Hanbaram 2 wind power plant project | 2021 | HANBARAM WIND POWER JSC |
| 69 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Phu Lac 2 substation - Phu Lac 2 wind power plant project | 2021 | TBW |
| 70 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Tan Phu Dong substation - Tan Phu Dong 2 wind power plant project | 2021 | GEC |
| 71 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Korea Tra Vinh substation - Korea Tra Vinh wind power plant project | 2021 | TWPC |
| 72 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Hoa Binh 2 substation - Hoa Binh 2 wind power plant | 2021 | |
| 73 | Supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 220kV Lao Bao substation | 2021 | EVNPTC2 |
| 74 | Installation, configuration and commissioning for Distributed Temperature Sensing system for underground cable from 110kV Cang Tien Sa substation to 110kV An Don substatioin | 2021 | EVNPTC2 |
| 75 | Supply materials, renovation for secondary cabinets system, configuration and testing for SCADA system of 220kV Vinh substation - "Increase capacity of 220kV Vinh (Hung Dong) substation from (125+250)MVA to 2x250 MVA" project | 2021 | EVNNPMB |
| 76 | Supply materials, renovation for secondary cabinets system; Supply, configuration, commissioning and testing for CSCS/SCADA system of 220kV Vinh substation - "Upgrading for the control protective system of 500kV, 220kV substations in the Northern Vietnam" project | 2022 | EVNNPMB |
| 77 | Supply materials, renovation for secondary cabinets system; Supply, configuration, commissioning and testing for CSCS/SCADA system of 220kV Vinh, 220kV Nghi Son substations - "Second circuit of Thanh Hoa - Nghi Son - Quynh Luu sections on 220kV Thanh Hoa-Vinh power line" project | 2022 | EVNNPMB |
| 78 | Supply materials, renovation for secondary cabinets system; Supply, configuration, commissioning and testing for CSCS/SCADA system of 220kV Than Uyen, 220kV Phu Ly, 220kV Vinh Yen substations - "Additional installation of 110kV reactors and 110kV capacitors in 220kV Than Uyen, 220kV Phu Ly, 220kV Vinh Yen substations" project | Doing | EVNNPMB |
| 79 | Supply secondary cabinets and auxiliary system; supply and configuration for CSCS/SCADA, FR/PMU/PQ system of 110kV Nam Tra My, Tra Don, Tra My substations | Doing | |
| 80 | Supply, installation, configuration and commissioning Power Forecast system for Tan Phu Dong 2 wind power plant | 2022 | GEC |
| 81 | Supply, installation, configuration and commissioning Power Forecast system for Lien Lap, Phong Huy, Phong Nguyen wind power plants | 2022 | PC1 |
| 82 | Supply secondary control & protection cubicles, CSCS/SCADA software, FR/PMU/PQ systems and configuration services for 110kV CNC 2. Project "New construction of 110kV CNC 2 substation and branch | 2022 | EVNHANOI |
| 83 | Supply secondary control & protection cubicles for 110kV Nghia Do substation. Project "Expanding Nghia Do 110kV substation" | 2022 | EVNHANOI |
| 84 | CSCS/SCADA configuration services for 220kV Dau Tieng substation. Project "Dau Tieng solar power plant" | 2022 | |
| 85 | CSCS/SCADA configuration services for 220kV Phuoc Thai 1 substation. Project "Phuoc Thai solar power plant" | 2022 | PMB3 |
| 86 | Supply secondary control & protection cubicles, CSCS/SCADA software, FR/PMU/PQ systems, power forecast system and configuration services. Project "Tan Phu Dong 1 wind power plant" | 2022 | GEC |
| 87 | Supply secondary control & protection cubicles, CSCS/SCADA software and configuration services for 220kV Hai Duong. Project "Installing 02 110kV bays in 220kV Hai Duong substation connecting to 110kV Hai Duong - Dong Nien power transmission line" | 2022 | NPTPMB |
| 88 | Installation, configuration and commissioning for Distributed Temperature Sensing system for underground cable of 110kV Binh Thai, 110kV Tan Cang. Project "Ben Thanh - Suoi Tien Metro" | 2022 | HCMC METRO |
| 89 | Supply, installation, and configuration for Operation Control Center of PC1 Group | 2023 | PC1 |
